ENGWE X26
1200W(Peak) 93 miles Triple Suspension Foldable E-bike
Please note:
1. Only sold in offline stores in the United States
2. US warehouse and after-sales maintenance center address: 2280 Valley Blvd, Pomona, CA 91768, US
3. Contact person for offline business in the United States:
Name: Ernie Huang
Phone: 215-992-2020
Email: ernie.huangtexas@gmail.com
Company:Qkey LLC (ENGWE California Branch)
Name: Mike Anzelde
Phone: 909-676-9079
Email: Anzelde2005@gmail.com
Company: Qkey LLC (ENGWE California Branch)
Specs
Motor | High-Speed Brushless Motor |
Material | 6061 Aluminum Alloy |
Tires | 26 x 4.0 Fat Tires |
Torque | 70 N.m |
Batteries | 48V10Ah Lithium-Ion Battery*1 |
48V19.2Ah Lithium-Ion Battery*1 | |
Mileage | 150 km (ECO Mode) |
Charging Time | About 8h |
Maximum Climbing Degree | 30° |
Brake | Hydraulic Disc Brakes |
Hub & Power | Integrated Hub Motor |
Transmission System | Shimano 8 Gears |
29.2Ah Battery Version Bike Weight | 43.6 kg (96 lbs) |
29.2Ah Battery Version Gross Weight | 52.47 kg (115 lbs) |
Maximum Load | 150 kg (330 lbs) |
Size
Rider Height | 5.5 (ft) -6.5 (ft) |
Payload Capacity | 150 kg (330lbs) |
Package Dimensions (LWH) | 158*35*87 cm |

A--Height | 114.7 cm |
B--Total Length | 196.1 cm |
C--Reach | 41.1 cm |
D--Standover Height | 76.1 cm |
E--Wheelbase | 122.1 cm |
F--Minimum Saddle Height | 93.8 cm |
G--Maximum Saddle Height | 121.5 cm |
Please note: There may be a difference of 0~5 cm between measured and actual data.
Folded Size | 110*72*120 cm |

A--Height | 120 cm |
B--Length | 110 cm |
C--Width | 72 cm |
Please note: There may be a difference of 0~5 cm between measured and actual data.
What's in the Box?
X26 E-bike | *1 |
Batteries | 48V10Ah Lithium-Ion Battery *1 |
48V19.2Ah Lithium-Ion Battery *1 | |
Battery Charger | *1 |
Assembly Tools | *1 |
Pedals | *2 |
Handle Bars Shipped Installed On Bike | *1 |
User Manual | *1 |
Display Manual | *1 |
Tool Kit | *1 |
Please note: The product you receive is based on the option you selected to order.
FAQ
Q1: Shipping information:
In stock: Once order confirmation has been completed, shipping preparations will begin
within the following 2 days and your order will be shipped on the third business day.
Pre-order: Please refer to the product page for detailed shipping times on pre-order items.
No stock: Please refer to the product page for detailed shipping times on out-of-stock items. You can expect to receive your product within 7 to 10 business days when it is shipped from our warehouse in the US.
Please note: Remote areas and islands are excluded from delivery.
Please reach out to our customer service team regarding special requirements or urgent delivery dates and we will endeavour to meet your needs.
Please check our Shipping Policy for additional information regarding delivery locations and costs.
Q2: X26 User Manual:
Please click here to view the X26 User Manual.
Q3: How to assemble X26 e-bike:
Please click here to view the video steps.
Q4: Unboxing and general bike setup:
Unboxing the X26
How to restore the X26 to factory default
X26 Throttle activation
X26 Throttle deactivation
How to change between KM and Miles on the X26
How to increase the speed limit to 50km/h (31 mph) on the X26
How to set the speed limit to 25km/h (15.53 mph) on the X26
Dual battery installation sequence on the X26
Q5: Where and how to buy the parts that you need:
Please reach out to the seller where you purchased the original item, if they are not able to provide it please reach out to our customer service at: service@engwe-bikes.com
Q6: My X26 won’t turn on or is losing power while riding:
Please click here to view an instructional video on solving these issues.







A Smooth Ride On Every Terrain
With the ENGWE X26 Fat Tires




High-Performance Series - Redefine Your Limits
Your next adventure starts here with the ENGWE X Series.
Travel without limitation, wherever the road may take you.
-
Shimano 8-Speed Gear Shifter
Seamless transition with a 160mm disk brake rotor and an IP65 waterproof speed sensor.
-
Alloy Pedals & Cleats
Durable and stable with anti-skid cleats & wider pedal area (80mm).
-
Aluminum Alloy Frame
Robust and lightweight frame.
-
Leather Seat
Comfortable and adjustable seat with a max height range of 25cm.
-
Hydraulic Disc Brakes
A front and rear brake provide powerful stopping power with a maximum braking distance of 12m.
-
Keeping You Safe & Lighting The Path Ahead
The High-Brightness front LED ensures that the road ahead is well-lit with its impressively long range.
-
Indicate Your Next Move
Ride safely and make your movements known on the road. Bright rear indicators keep you out of harm’s way on your journeys.
